size	Model	brightness	resolution	Display area (mm)	voltage (v)	Port
3.5"	STVI035WT-01	400 cd/m2	320 x240	70.1 x52.6	DC6-40	RS232/USB
4.3"	STVI043WT-01	400 cd/m2	480 x272	95x 53.9	DC6-35	RS232/USB
5"	STVI050WT-01	400 cd/m2	480 x272	110.9 x62.8	DC6-35	RS232/USB
5"	STVI050WT-02	300 cd/m2	640 x480	101.6 x76.2	DC6-35	RS232/USB
5"	STVI050WT-03	400 cd/m2	800 x480	108 x64.8	DC6-35	RS232/USB
5.6"	STVI056WT-01	300 cd/m2	640 x480	112.9 x84.7	DC6-40	RS232/USB
7"	STVI070WT-01	400 cd/m2	800 x480	154.1 x85.9	DC6-35	RS232/USB
7"	STVI070WT-03	500 cd/m2	1024 x600	154.1 x85.9	DC6-35	RS232/USB
8"	STVI080WT-01	400 cd/m2	800 x600	162 x121.5	DC6-40	RS232/USB
8"	STVI080WT-03	400 cd/m2	1024 x768	162 x121.5	DC6-40	RS232/USB
9.7"	STVI097WT-01	300 cd/m2	1024 x768	196.6 x147.5	DC6-40	RS232/USB
10.1"	STVI101WT-01	500 cd/m2	1024 x600	222.7 x125.3	DC6-40	RS232/USB
10.4"	STVI104WT-01	350 cd/m2	800 x600	211.2 x158.4	DC6-40	RS232/USB

size	Model	brightness	resolution	Display area (mm)	voltage (v)	Port
3.5"	STVA035WT-01	1000 cd/m2	320 x240	70.1 x53.8	DC6.0-40	RS232//USB
4.3"	STVA043WT-01	1000 cd/m2	480 x272	95x 53.9	DC6.0-35	RS232//USB
5"	STVA050WT-01	800 cd/m2	800 x480	108 x64.8	DC6.0-40	RS232//USB
5.7"	STVA057WT-01	1000 cd/m2	640 x480	115.1 x86.8	DC6.0-40	RS232/USB
7"	STVA070WT-01	1000 cd/m2	800 x480	154.1 x85.9	DC6.0-35	RS232/USB
8"	STVA080WT-01	900 cd/m2	800 x600	162 x121.5	DC6.0-40	RS232/USB
10.1"	STVA101WT-01	1000 cd/m2	1024 x600	222.7 x125.3	DC6.0-40	RS232/USB
12.1"	STVA121WT-01	300 cd/m2	800 x600	246 x184.5	DC10.2-40	RS232/RS485/USB
15.1"	STVA151WT-01	300 cd/m2	1024 x768	304.1 x228.1	DC10.8-40	RS232/RS485/USB

size	Model	brightness	resolution	Display area (mm)	voltage (v)	Port
3.5"	STVC035WT-01	300 cd/m2	320 x480	49x 73.4	DC6.0-15	RS232/RS485/TTL/USB
4.3"	STVC043WT-01	350 cd/m2	480 x272	95x 53.9	DC6.0-35	RS232/RS485/TTL/USB
5"	STVC050WT-01	350 cd/m2	480 x272	110.9 x62.8	DC6.0-35	RS232/RS485/TTL/USB
5"	STVC050WT-03	400 cd/m2	800 x480	108 x64.8	DC6.0-35	RS232/RS485/TTL/USB
7 ''	STVC070WT-01	400 cd/m2	800 x480	154.1 x85.9	DC6.0-35	RS232/RS485/TTL/USB
7 ''	STVC070WT-03	280 cd/m2	1024 x600	154 x86	DC6.0-35	RS232/RS485/TTL/USB
8 ''	STVC080WT-01	300 cd/m2	800 x600	162 x121.5	DC6.0-35	RS232/RS485/TTL/USB
10.1 ''	STVC101WT-01	300 cd/m2	1024 x600	222.7 x125.3	DC6.0-35	RS232/RS485/TTL/USB

size	Model	brightness	resolution	Display area (mm)	piezoelectric (v)	Port
4.3"	STeWin4300	300 cd/m2	480 x272	97x 55	DC9-28	RS232/RS485//USB/Net
5.7"	STeWin5700	300 cd/m2	640 x480	115 x86	DC9-28	RS232/RS485//USB/Net
7"	STeWin7000	300 cd/m2	800 x480	154 x93	DC9-28	RS232/RS485//USB/Net
8.4"	STeWin8400	400 cd/m2	800 x600	170 x128	DC9-28	RS232/RS485//USB/Net
10.2"	STeWinA200	350 cd/m2	800 x600	222 x134	DC9-28	RS232/RS485//USB/Net
10.4"	STeWinA400	350 cd/m2	800 x600	213 x160	DC9-28	RS232/RS485//USB/Net
